HQ400-2000B Servo ماكينة CNC لثني قضبان النحاس
Classification :
PRODUCT DETAILS
HQ400-2000B Servo ماكينة CNC لثني قضبان النحاس
HQ400-2000B Servo ماكينة CNC لثني قضبان النحاس is an LT busbar machine solution for repeatable CNC-controlled flat, vertical and shaped bending. It is intended for switchgear, transformers and busbar assembly lines in Saudi Arabia and the Middle East. Final capacity and tooling should be confirmed against the required busbar width, thickness, material and drawing.
المواصفات الفنية
| Model | HQ400-2000B |
| Nomianl Pressure | 400KN |
| Hydraulic Cylinder Stroke | 250mm |
| Main Motor Power | 5.5kw |
| Gauge Length | 2000mm |
| Gauge Accuracy | +/-0.15 |
| Bending Accuracy | +/-0.3° |
| Bending Head(Y Axis) | Fastest 5m/min; low: 1.25m/min |
| Max Moting Speed of Side striker(X Axis) | 15m/min |
| Y-axis Repeat Positioning Accuracy | +/-0.02 |
| Horizontal Bending Max.Size | 15mm x 160mm |
| Vertical Bending Max.Size | 12mm x 120mm |
| Y-axis Servo Motor Power | 5.5kw |
| X-axis Servo Motor Power | 0.75kw |
| Weight | 3300kg |
| Size | 4300mm x 1450mm x 1850mm |
التطبيقات
This model is applicable to switchgear, transformers and busbar assembly lines. Suitability depends on the final workpiece drawing and production target.
صور وفيديو المنتج
الأسئلة الشائعة
What information is needed for model selection?
Provide busbar material, maximum width and thickness, required operations, hole drawings, production volume and power standard.
Can the machine process both copper and aluminium busbars?
Most configurations support both materials within their stated capacity. Confirm the exact alloy and dimensions before ordering.
Are tooling and commissioning available?
Tooling, operating guidance and commissioning options can be configured for the project and destination.
How is the final configuration confirmed?
The engineering team checks the drawings, process sequence, capacity and electrical requirements before the quotation is finalised.
How can I request a quotation?
Submit the form below with the model, busbar dimensions and required operations for an application-specific proposal.
